Model LS17
BAL 1
TUNER CD
MONITOR
PROC
BAL 2 AUX
POWER
MUTE VOL DN VOL UP
MODEL LS17R
Turns power on/off.
Select one of five available audio inputs.
Adjusts volume up. Visible
numerically 1–20 on LED display.
Adjusts volume down. Visible
numerically 1–20 on LED display.
Input for external A–V processor. Provides
unity gain, disabling volume controls.
Mutes output of LS17.
Routes the monitor input signal
to the main outputs.
ln
NOTE: All LS17 functions are
available on the LS17R hand held
remote controller. All functions are
indicated on the front panel as they
are selected. See “Description of
Controls” in this manual for more
information.
