Audio Technica AT2020USB+ User Manual

3
Part names and functions
1
Microphone
2
Indicator lamp
Lights blue to show that the microphone is
receiving power via USB.
3
Mix control dial
Adjusts the balance of the volume level of the
sound source stored on the computer and the
monitored volume level of the audio being
input.
4
Headphone level control dial
Adjusts volume of headphone output.
5
USB terminal (USB Type-B)
Use to connect the included USB cable.
6
Headphone jack
(3.5 mm (1/8") stereo mini-jack)
Use to connect the headphones.
7
USB cable
(3.1 m (10'), USB Type-A - USB Type-B)
2
1
3 4
5
7
6
Front Rear

Audio Technica AT2020USB+ Specifications

General

Type	Studio microphone
Bit rate	16 bit
Sample rate	48 kHz
Microphone frequency	20 - 20000 Hz
Microphone direction type	Cardioid
USB port	Yes
Connectivity technology	Wired
Cable length	3.1 m
Product color	Black
Number of products included	1 pc(s)
Battery operated	No

Weight and Dimensions

Microphone weight	374 g
