User Manual
IN-EARHEADPHONESATH-CKR70
Thank you for purchasing this product. Before using the product, read through the user manual
to ensure that you will use the product correctly. Please keep this manual for future reference.
■Care
■Name of each parts
Conrm each part before using the product.
Although this product was designed to be used safely, failing to use it correctly may result
in an accident. To ensure safety, observe all warnings and cautions while using the product.
■About the eartips
■Sizes
The product comes with silicon eartips in four
sizes (XS, S, M and L). At the time of purchase,
the M size silicon eartips are attached and
positioned in standard position. To ensure that
you will enjoy the best sound quality, it may be
necessary to change the size and /or position to
what is best suited for you, and adjust the eartips
inside your ears for a snug t.
■Cleaning the eartips
Remove eartips from the product and clean them
with a diluted detergent. After cleaning, dry
before use.
■Replacing the eartips
Remove each old eartip, and mount the new
eartip over the stem up to the base of the stem.
*The eartips are designed to t tightly to the
product so that they will not come loose
unintentionally.
■Using headphones
■Specifications
■Warnings
■ Safety precautions
●
For long-time storage, keep the product in a
well-ventilated place without high
temperatures and humidity.
●
Refer to ''Cleaning the eartips'' in ''About the
eartips'' to learn how to clean the eartips.
●
Follow applicable laws regarding mobile
phone and headphone use if using the product
while driving.
●
Do not use the product in places where the
inability to hear ambient sound presents a
serious risk (such as at railroad crossings, train
stations, and construction sites).
●
The product effectively shields external
sound, so you may not hear sound around you
clearly while wearing the product. Adjust the
volume to a level where you can still hear
background sound and monitor the area
around you while listening to music.
●
Store the eartips out of the reach of small
children.
■Cautions
●
To ensure compatibility and correct usage,
always consult the user manual of any device
before connecting the product to it.
●
Audio-Technica will not be liable in any way for
any loss of data in the unlikely event that such
losses should occur while using the product.
●
On public transport systems or in other public
places, keep the volume low so as not to
disturb other people.
●
Minimize the volume on your audio device
before connecting the product in order to avoid
hearing damage from sudden exposure to
excessive volume.
●
When using the product in a dry environment,
you may feel a tingling sensation in your ears.
This is caused by static electricity accumulated
on your body, not by product malfunction.
●
Do not subject the product to strong impact.
●
Do not store the product under direct sunlight,
near heating devices or in a hot, humid or dusty
place. Do not allow the product to get wet.
●
Be sure to purchase the appropriate
conversion plug adaptor when connecting
the product to equipment with other than a
3.5 mm (1/8”) stereo headphone jack.
●
Lengthening the headphone cable requires a
separate extension cable available from your
dealer.
1. Lower the volume on the device you intend
to use, then connect to the device's
headphone jack.
2. Make sure to place each eartip
(LEFT/RIGHT) in the correct ear.
3.
Turn on your audio device, and adjust
volume as necessary.
*Also read instruction manual of your audio device.
Get into the habit of regularly cleaning the
product to ensure that it will last for a long time.
Do not use alcohol, paint thinners or other
solvents for cleaning purposes.
●
Use a dry cloth to clean the headphones.
Do
not allow the cloth to touch the area from the
sound producing area because it is more
susceptible to damage.
●
Use a dry cloth to clean the cable of any sweat
or dirt. Failure to clean the cable may cause it
to deteriorate and harden over time, resulting
in malfunction.
●
Wipe the plugs on the cable with a dry cloth if
dirty. Using the plugs without cleaning them
can cause sound interruption or distortion.
1 Housing
2 Eartip
3
LEFT/RIGHT (L/R) indicator
4 Bushing
5 1.2m (3.9') cable
6 3.5 mm (1/8") gold-plated
stereo mini-plug (L-shaped)
Type ：Dynamic
Driver ：11.8 mm
Sensitivity ：108 dB/mW
Frequency response ：5 to 40,000 Hz
Maximum input power ：200 mW
Impedance ：19 ohms
Cable length ：1.2 m (Y type*)
Plug ：3.5 mm (1/8") gold-plated stereo mini-plug (L-shaped)
Weight (without cable) ：Approx. 8 g (0.28 oz)
Included accessories ：Pouch, Eartips (XS,S,M,L)
Sold separately ：Eartips (ER-CKM55XS,S,M,L)
* Left and right cable length are the same.
(For product improvement, this product is subject to modication without notice.)
Audio-Technica Corp.
2-46-1 Nishi-naruse, Machida, Tokyo 194-8666, Japan
2016
Audio-TechnicaCorp.
CB
1
5
6
A
A
B
C
●
If you begin to feel unwell while using the
product, discontinue use immediately.
●
To prevent damage to your hearing, do not
raise the volume too high. Listening to loud
sound for an extended period may cause
temporary or permanent hearing loss.
●
Discontinue use if skin irritation results from
direct contact with the product.
●
Do not disassemble, modify or attempt to
repair the product.
●
When removing the product from your ears,
check to make sure the eartips are still
attached to the main unit. If the eartips
become lodged in your ears and you are unable
to remove them, consult a physician at once.
●
When the product is used for a long time, the
product may become discolored due to
ultraviolet light (especially direct sunlight) or
wear.
●
The cable may become caught or severed if
the product is placed in a bag or pocket without
adequate protection. Always store the product
in the included pouch.
●
Connect/disconnect the cable by holding the
plug. Pulling directly on the cable can result in a
broken wire and the risk of electric shock.
Sound
producing area
Acoustic tube
The left bushing
has a protruding part.
2
4
3
Digital audio player
or other device
