Mediant MSBRs 38 Document #: LTRT-31828
Security Setup
S 192.168.11.0/24 [1/1] is directly connected, GRE 1
S 192.168.12.0/24 [1/1] is directly connected, GRE 1
S 192.168.13.0/24 [1/1] is directly connected, GRE 1
MSBR2#
A debug capture is run while pinging from MSBR1 VLAN 1 to MSBR2 VLAN 1, using the
command:
debug capture data interface gigabitethernet 0/0 proto all host
180.1.1.1
While the ping command was issued in the following matter:
ping 192.168.1.1 source data source-address interface vlan 1
Note that the traffic is encrypted and therefore, only ESP packets are shown.
# debug capture data interface gigabitethernet 0/0 proto all host
180.1.1.1
tcpdump: verbose output suppressed, use -v or -vv for full
protocol decode
listening on eth1.4010, link-type EN10MB (Ethernet), capture size
96 bytes
10:17:24.936266 00:90:8f:59:4b:56 > 00:90:8f:89:35:a9, ethertype
IPv4 (0x0800), length 150: 180.1.1.1 > 180.1.1.2:
ESP(spi=0xce91a06e,seq=0xc), length 11
10:17:24.936858 00:90:8f:89:35:a9 > 00:90:8f:59:4b:56, ethertype
IPv4 (0x0800), length 150: 180.1.1.2 > 180.1.1.1:
ESP(spi=0x3647ff5a,seq=0xc), length 11
10:17:25.933155 00:90:8f:59:4b:56 > 00:90:8f:89:35:a9, ethertype
IPv4 (0x0800), length 150: 180.1.1.1 > 180.1.1.2:
ESP(spi=0xce91a06e,seq=0xd), length 11
10:17:25.933653 00:90:8f:89:35:a9 > 00:90:8f:59:4b:56, ethertype
IPv4 (0x0800), length 150: 180.1.1.2 > 180.1.1.1:
ESP(spi=0x3647ff5a,seq=0xd), length 11
10:17:26.935143 00:90:8f:59:4b:56 > 00:90:8f:89:35:a9, ethertype
IPv4 (0x0800), length 150: 180.1.1.1 > 180.1.1.2:
ESP(spi=0xce91a06e,seq=0xe), length 11
10:17:26.935625 00:90:8f:89:35:a9 > 00:90:8f:59:4b:56, ethertype
IPv4 (0x0800), length 150: 180.1.1.2 > 180.1.1.1:
ESP(spi=0x3647ff5a,seq=0xe), length 11
10:17:27.934135 00:90:8f:59:4b:56 > 00:90:8f:89:35:a9, ethertype
IPv4 (0x0800), length 150: 180.1.1.1 > 180.1.1.2:
ESP(spi=0xce91a06e,seq=0xf), length 11
10:17:27.934665 00:90:8f:89:35:a9 > 00:90:8f:59:4b:56, ethertype
IPv4 (0x0800), length 150: 180.1.1.2 > 180.1.1.1:
ESP(spi=0x3647ff5a,seq=0xf), length 11
10:17:29.934720 00:90:8f:59:4b:56 > 00:90:8f:89:35:a9, ethertype
ARP (0x0806), length 60: arp who-has 180.1.1.2 tell 180.1.1.1
