Configuration Guide 7. IPSec Tunneling
Version 7.2 43 Security Setup
7.1.3.1.4 Import Device Certificate Using Signing Request
1. Go to the PKI CLI section:
#configure data
MSBR(config-data)#crypto isakmp
2. Create certificate fields names, such as country codes, state, Organization name etc
using the command "certificate subject field-set <FIELD NAME> <FIELD VALUE>":
(config-isakmp-pki)#certificate subject field-set organization
AC
(config-isakmp-pki)#certificate subject field-set country IL
(config-isakmp-pki)#certificate subject field-set common-name
MSBR-7
3. Generate a signing request:
(config-isakmp-pki)#certificate signing-request
Certificate signing request:
-----BEGIN CERTIFICATE REQUEST-----
MIICgTCC…
---output omitted---
…zxcsF
-----END CERTIFICATE REQUEST-----
Send this request to your security administrator for signing,
then upload the new signed certificate to the device.
4. Using the signing request, obtain the device certificate and then import the obtained
certificate using the import command "Certificate import".
(config-isakmp-pki)#certificate import
Enter data below. Type a period (.) on an empty line to
finish.
-----BEGIN CERTIFICATE-----
MIIEoDCCAoigAwIB
---output omitted---
-----END CERTIFICATE-----
.
File replaced.
MSBR(config-isakmp-pki)#
5. Check if the imported certificate matches the private key with which it was generated:
MSBR-31(config-isakmp-pki)# certificate status
Certificate subject: /C=IL/CN=MSBR-31
Certificate issuer :
/C=IL/ST=CENTER/L=LOD/O=Audiocodes/OU=R&D/CN=ca.local/emailAdd
ress=timg@audiocodes.com
Signature Algorithm: sha256WithRSAEncryption
Time to expiration : 369 days
Key size: 2048 bits
Active sockets: 0
The currently-loaded private key matches this certificate.
