Mediant MSBRs 56 Document #: LTRT-31828
Security Setup
ppp authentication mschap
ppp authentication mschapv2
idle-timeout 60
ipsec key LinePass!1
no shutdown
exit
The above configuration configures address 192.168.1.3 to 192.168.1.8 for L2TP clients.
The chap, mschap, mschap version two protocols are selected for the authentication. The
key "LinePass!1" is used for the IPSec encryption between the client and server.
The following is the user configuration for the clients:
vpn-users
user AudioCodes key P@ssw0rd
exit
Note that show running-config displays the passwords and keys in obscured format.
To configure Windows 7 to connect to the L2TP server:
1. Click the Windows icon on the left, and in the search text box, type "vpn".
Figure 8-1: VPN Console
