6 | Page
Specification RXVCam10
Minimum
Illumination
0.5Lux(F1.8, AGC ON)
Focus Manual
AF Fixed
Backlight contrast On/off
Exposure Auto / Manual
Video Adjustments Brightness, Definition, Saturation, Contrast, white balance, gain, anti-flicker,
low brightness compensation adjustable
SNR >50dB
Output Parameter
Video Output USB2.0(Power, upgrade support)
Video Compression MJPEG,YUV2,H.264,H.265
Other Parameters
Input Voltage 5V
Input Current 500mA (max)
Power 2.5W(max)
Store Temperature -10℃ ~ +60℃
Store Humidity 20% ~ 95%
Working
Temperature
-10℃ ~ +50℃
Working Humidity 20% ~ 80%
Dimension 102mm*46mm*30mm
Weight 0.15kg
Accessory User Manual, Warranty card
