AudioEngine N22 User Manual

7
audioengine N22 setup guide
Other Features
Headphone Out - For headphone enthusiasts the N22 includes a high-
performance, low-noise headphone amplier which works well with all
types of headphones. Even if you don't connect speakers to your N22 the
headphone amplier will make your iPod or computer sound better
through headphones. Keep in mind that permanent hearing loss may
occur if earbuds or headphones are used at high volume so be sure to set
the volume to a safe level.
Line Out - The N22 includes a variable preamp output so you can connect
a subwoofer, external amplier, or Audioengine wireless adapter and
control the volume of the line-out from the front panel.
USB Power - The USB power port allows you to charge and power your
iPod, iPhone, Audioengine wireless adapters or any other USB powered
product through the USB connector on the rear panel. Note that this is for
power only, not USB audio or data transfer.
For a complete list of product features and specications go to:
www.audioengineusa.com

AudioEngine N22 Specifications

General

Amplifier class	A/B
Input sensitivity	410 mV
Audio output channels	- channels
Peak power per channel	1800 W
Signal-to-Noise Ratio (SNR)	95 dB
Total Harmonic Distortion (THD)	0.02 %
AC (power) in	Yes
USB 2.0 ports quantity	1
Speakers connectivity type	RCA
Purpose	-
Product color	Black
Volume control	Rotary
Cables included	AC, Audio (3.5mm), RCA
Connectivity technology	Wired & Wireless
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Package weight	4600 g

Weight and Dimensions

Depth	140 mm
Width	70 mm
Height	180 mm
Weight	1600 g
