S6 Wireless Subwoofer Setup
Here are two of the most common connection options to connect the S6 subwoofer to your music system, stereo receiver, or
powered speakers.
Input
Input
Subwoofer input
Left/LFE
Right
Connect a 3.5mm mini-jack audio cable from an output of your
stereo receiver, powered speakers, or any music system with an
output, to the S6 subwoofer input.
1
1
1
Connect an RCA stereo cable from an output of your stereo
receiver, powered speakers, or any music system with an
output, to the S6 subwoofer input.
1
If your stereo receiver or music system has a single RCA sub out or LFE output, connect an RCA cable from this output
to the S6 sub RCA left (L) input.
S6 Subwoofer Setup
V01-1910
S
6
S
6
Auto
on
O
Standby
Power on - green
Standby - amber
Auto
on
O
Standby
