9: Specifications
(Measurement made with 230V power supply)
Output Voltage
4.2Vrms ±0.1 (Balanced)
2.1Vrms ±0.1 (Unbalanced)
Output Impedance 10Ω
Total Harmonic Distortion (THD) <0.002% (1kHz, 0dB, 20Hz ~ 20kHz, A weighted)
Frequency Response 20Hz - 20kHz (± 0.2dB)
Signal to Noise Ratio (S/N)
<-100dB A Weighted (Balanced)
<-98dB A Weighted (Unbalanced)
Dyanmic Range (A Weighted)
>100dB (Balanced)
>98dB (Unbalanced)
Crosstalk (@1kHz)
<-130dB (Balanced)
<-120dB (Unbalanced)
Standby Power Consumption <0.5W
Power Requirements
240V ~ 50 - 60Hz
230V ~ 50 - 60Hz
115V ~ 50 - 60Hz
100V ~ 50 - 60Hz
Dimension(mm) (W x H x D) 444 X 80 X 317
Carton size(mm) ( W X H X D) 500 x 140 x 455
Weight
6.0kg (Net)
7.5kg (Gross)
