TO POWER SUPPLY
CAMERA
3 4 1
POWER
BRIGHTNESS
+
–
4
TRIGGER (+12V)
POWER (+12V)
POWER (GND)
3
1
WIRING DIAGRAM
1
2
3
4
BLUE – TRIGGER WIRE
EMPTY
RED – 12V DC
BLACK – GROUND
