Audiovox PurSuit PRO9056C User Manual

128-8791b
3 of 24
3
6 Pin Power / Start Harness #1123742
1
2
3
4
5
6
Purple Accessory (+)
Blue Ignition 1 (+)
Red Battery 2 - 12V (+)
Red/White Battery 1 - 12V (+)
Yellow Starter Output
Green Ignition 2 (+)
1
2
3
4
Black/Blue Factory Disarm / Pulse Beffore Start (-)
Black/Green Factory Arm / Pulse After Start (-)
Black/Red Pulse After Shutdown (-)
Black/Yellow Pulse During Crank (-)
Green/Orange Tachometer Input
12 Pin Main Wiring Harness #1123751
1
2
3
4
5
6
7
8
9
10
11
12
Yellow/Black (+) Output To Control Factory Alarm
Green/Yellow Diesel Wait To Start Input
Brown Positive Inhibit Shutdown Input (+)
Brown/Black Brake Shutdown Input (+)
Black Chassis Ground
Gray/Black Negative Inhibit Shutdown Input (-)
Light Blue Ground Output While Running (-) 300mA
Gray Shutdown Input (-)
White Parking Light Output
White Parking Light Input
No Connection
4 Pin Alternate Output Harness #1122585
