Receiver
Speaker
Terminal
Connection to
Amplifier or Receiver
We recommend standard 16-gauge speaker wire (or
larger multi-stranded cable) for connecting this
speaker, to your receiver. When using more than one
spe ake r it is importan t that ea ch spe ake r be
connected in the same way to each channel of the
amplifier. This ensures that the speakers operate “in
phase,” that is, that their cones move back and forth
together to yield fullest bass response and proper
stereo imaging. (see illustration below).
After the speakers are connected, you can check for
proper phasing by means of a simple listening test.
Place the speakers face-to-face, just a few inches
ap a r t . S e t y o u r r e c e i v e r t o m o n o , p la y s o m e
music, a n d r e v e r s e t h e c o n n e c t i o n s t o o n e
speaker. Whichever way yields fuller and louder
sound is the correct connection.
Speaker Placement
Your goal, and ours, is to achieve flat frequency
response and optimum stereo imaging in spite of any
undesirable acoustic properties your room may have.
Placement is critical in matching your new speakers to
the room, and to your taste.
The New Vision loudspeakers are designed for floor
pl a c e m e n t. T h e i r h e i g h t a n d d r i v e r s p a c i n g a r e
de signed to give you a good star t tow ard o ptimum
imaging and frequency response. If you have the time and
inclination you can experim ent with va rious place-
ments, with the knowledge that room acoustics can often
produce large apparent differences in the sound for small
changes in placement. For example, although the speaker
may be located at any height above the floor, locating the
tweeter somewhere near ear level often provides the
most realistic musical imaging.
Another rule of thumb is that the proportion of bass
increases as you move a speaker closer to intersecting
room surfaces (wall, ceiling and floors), and that the most
bass (often times too much) results from placement
in a corner at the floor or ceiling. With these rules in
mind, you should be able to obtain the balance you prefer
with reasonable ease.
Power Handling
As with any product, the New Vision have their operating limits,
and consistently exceeding those limits will damage the
speakers. Fortunately, there is an audible warning when those
limits are reached: distortion, such as “fuzzy” or “gritty”
sound which is usually the result of driving an amplifier beyond
its undistorted power capability.
Overdriving an amplifier or sound processor –including one with
a modest power rating–in turn overdrives the speaker so that
permanent damage results. Should y ou enco unt er the
warning of distortion at loud v o l u me l e v e ls, n o h a r m
will be done if you immediately turn down the volume to
a point where the d i s t o r t i o n d i s a p p e a r s . H o w e v e r ,
prolonged operation at distorted volume levels can damage
the speaker system, and such damage is not covered by the
warranty.
Note:
If you intend to play more than one pair of Advent
loudspeakers simultaneously, please contact your amplifier/
receiver manufacturer to verify low impedance capability of
your equipment.
NEWVISION
™
Tower
1.
4.
2-Way Tower
(4) 3" Polypropylene Woofers
1/2" Mylar Dome Tweeter
Frequency Response: 60Hz-25kHz
Nominal Impedance: 4-8 ohms
Sensitivity: 89dB
Power Handling: 100 Watts RMS/ 200 Watts Peak
Finish: Aluminum
Dimensions: 40.25”Hx3.82”Wx9.625”D
Video Shielded
Specifications
Enceintes acoustiques de type tour à 2 voies
(4) haut-parleurs de graves en polypropylène de 3 po
Haut-parleur d’aigus à dôme Mylar de 1/2 po
Réponse en fréquences : 60Hz à 25kHz
Impédance nominale : 4-8 ohms
Sensibilité : 89dB
Alimenter le Maniement: 100 Watts RMS/ 200 Watts Peak
Fini : Aluminium
Dimensions : 40,25 po H x 3,82 po L x 9,625 po
Blindage vidéo
Torre acústica de 2 vías
(4) Woofers de Polipropileno de 3 “
Tweeter de cúpula Mylar de 1/2”
Respuesta de frecuencia: 60Hz-25kHz
Impedancia nominal: 4-8 ohmios
Sensibilidad: 89dB
Accione el Manejo: 100 Vatios RMS/ 200 Vatios Peak
Acabado: Aluminio
Dimensiones: 40.25”alto x 3.82”ancho x 9.625”largo
Video blindado
NEWVISION
™
Tower
