Audison LR 180 XR User Manual

8
33
ITALIANO
DATI TECNICI
ALIMENTAZIONE 11 ÷ 16 VDC
ASSORBIMENTO A VUOTO 0,7 A
ASSORBIMENTO MAX (Pot. Nominale) 12 A
POTENZA NOMINALE CONT. (Toll. +10 %; -5 %)
1Ch x 4 Ohm; 0,3 % THD; 12 VDC 80 W (RMS)
POTENZA CONTINUA (1 Ch x 4 Ohm; 13,8 VDC) 85 W (RMS)
POTENZA CONTINUA (1 Ch x 2 Ohm; 13,8 VDC) 150 W (RMS)
POTENZA CONTINUA (1 Ch x 1 Ohm; 13,8 VDC) 245 W (RMS)
DISTORSIONE THD (1 KHz; 90% Pot. nominale) 0,07 %
BANDA PASSANTE (-3 dB; Pot. nominale) 4 Hz ÷ 70 KHz
FATTORE DI SMORZAMENTO (4 Ohm) 120
TEMPO DI SALITA 4,5 µS
RAPPORTO SEGNALE RUMORE 98 dBA
SENSIBILITA' D'INGRESSO 0,15 V ÷ 1,5 VRMS
IMPEDENZA D'INGRESSO 15 KOhm
IMPEDENZA DI CARICO 1; 2; 4; 8 Ohm
REMOTE IN 3 ÷ 16 VDC
REMOTE OUT 12 VDC
MUTE IN 3 ÷ 16 VDC
MUTE OUT 12 VDC
DIMENSIONI (BxAxL) 175 x 50 x 290 mm
ENGLISH
TECHNICAL DATA
POWER SUPPLY 11 ÷ 16 VDC
IDLING CURRENT 0.7 A
MAX CONSUMPTION (Nominam Pwr) 12 A
NOMINAL POWER CONT. (Tol. +10%; -5%)
1 Ch x 4 Ohms; 0.3% THD; 12 VDC 80 W (RMS)
POWER CONT. (1 ch x 4 Ohms; 13.8 VDC) 85 W (RMS)
POWER CONT. (1 ch x 2 Ohms; 13.8 VDC) 150 W (RMS)
POWER CONT. (1 ch x 1 Ohms; 13.8 VDC) 245 W (RMS)
DISTORTION THD (1 KHz; 90% Nominal Pwr) 0.07 %
BANDWIDTH (-3 dB; Nominal Pwr) 4 Hz ÷ 70 KHz
DAMPING FACTOR (4 Ohms) 120
RISE TIME 4.5 µS
SIGNAL / NOISE RATIO 98 dBA
INPUT SENSITIVITY 0.15 V ÷ 1.5 VRMS
INPUT IMPEDANCE 15 KOhms
LOAD IMPEDANCE 1; 2; 4; 8 Ohms
REMOTE IN 3 ÷ 16 VDC
REMOTE OUT 12 VDC
MUTE IN 3 ÷ 16 VDC
MUTE OUT 12 VDC
SIZE (WxHxD) 175 x 50 x 290 mm (6.89 x 1.97 x 11.42 inch)
LR 180 M
LR 1140 XR - LR 180 XR
COMPOSITION DU BORNIER DE CONNECTIONS
