Audison SR 5.600 - 8 INSTALLATION EXAMPLES; 1 CH: Filtered Subwoofer Setup

User’s Manual
54
SR 1.500
SUB
Rem. Vol.
Control
INPUT
SPEAKER
IN
to OTHER
AMPLIFIERS
USE PRE-IN
OR SPEAKER IN:
NOT BOTH
SUBWOOFER(min1Ω)
L
L
L
R
R
R
SOURCE
1CH: FILTERED SUBWOOFER
ON
SUB
LEVEL
SUB
LO PASS
8
INSTALLATION EXAMPLES
Adjustment
CONTROLS
Not
AVAILABLE
::
Set-up
CONTROLS
:
SPEAKERS CABLE
16 mm / 0.62 in.
