Audison SR 5.600 User Manual

User’s Manual
67
3CH: FRONT + SUB SR 6.600
INPUTS: A - B - C
Adjustment
CONTROLS
Not
AVAILABLE
::
Set-up
CONTROLS
:
OUTPUTS
L L
L
L
R
R
R R
RL
A Ch (L)
INPUT
B Ch (R)
INPUT
C Ch
INPUT
PASSIVE FILTERS
FRONT
SOURCE
HI
ON
ONONON
X1
SPEAKER IN
C Ch
SPEAKER IN
B Ch (R)
SPEAKER IN
A Ch (L)
USE PRE-IN
OR SPEAKER IN:
NOT BOTH
SUBWOOFER
min2Ω(L+R)
SUB WOOFER
LEVELS LO-PASS
LO
HI
FRONT R
LEVELS HI-PASS
FRONT L
LEVELS HI-PASS
SPEAKERS CABLE
16 mm / 0.62 in.

Audison SR 5.600 Specifications

General

Channels	5
Signal to Noise Ratio	> 100 dB
Total Harmonic Distortion	< 0.05%
Input Sensitivity	0.2V - 6V
Operating voltage	11V - 15V
Crossover	High-pass / Low-pass
Frequency Response	10 Hz - 30 kHz
