Step 6.
Mount the long black rubber fuel line joiner to the base of the unit using a mini clamp to secure
it and on the opposite side Insert the fuel line into the black joiner on the unit side at least 20mm
in and use a minicamp to secure it. (Tip! to ensure you have pushed the fuel line in far enough
use a texter and mark the 20mm from the end of the fuel line, use some lubricant to force it in
up to the marked line so you know it's gone in far enough.)
Step 7.
Step 8.
Mount the exhaust pipe to the base of the main unit using the supplied heavy-duty clamp. (Don’t
mount the muffler yet!) Note: Ensure that the heavy-duty clamp bolt is on the inside of the unit
as per the image below.
Mount the cold air intake pipe to the base of
the main unit (Next to the black fuel line
joiner) secure with the supplied clamp.
(Don't mount the air filter yet!) Note: Ensure
that the clamp screw is on the inside of the
unit as per the image below.
