AUNE X8 MAGIC DAC - Coaxial and Optical Operation Guide

Diagram 2
1. Connect the X8 and a digital audio device (eg. digital transport, computer main board with digital
outputs) (diagram 2)
2. Set input to COAX or OPT
3. Play music on the connected device
4. Connect the X8 and an amplifier / active speakers via AUDIO OUT (fixed line out)
5. Adjust volume (PREAMP OUT only)
Via Coaxial / Optical
COAX IN
COAX OUT
Operations
