Balance
Adjusts the relative volume between left and right channels.
X-over
Setting low and high pass filters (LPF and HPF). The settings for this menu item
will be different for 2-WAY / 3-WAY!
Subwoofer set
Turns on / off the subwoofer.
Fader
Adjusts the relative volume between front and rear speakers.
Sub-W level
Adjusts the volume level of the subwoofer (from -13 dB to +13 dB).
Sub-W stereo
Switching the operating mode of the RCA outputs of the subwoofer (Mono / Stereo).
AUDIO - sound settings
Tweeter - treble setting
FRQ (FREQUENCY) - Frequency selection: 1 / 1.6 / 2.5 / 4/5 / 6.3 / 8/10 / 12.5 kHz.
GAIN LEFT - volume level (left channel), from -8 to 0 dB.
GAIN RIGHT - volume level (right channel), from -8 to 0 dB.
Front HPF - setting the HPF of the front speakers
F-HPF FRQ - Cutoff frequency: TROUGH (off) / 30 / 40 / 50 / 60 / 70 / 80 / 90 /
100 / 120 / 150 / 180 / 220 / 250 Hz.
F-HPF SLOPE - Slope: 6 / 12 / 18 / 24 dB per octave.
F-HPF GAIN - volume level, from -8 dB to 0 dB.
Rear HPF - setting the HPF of the rear speakers
R-HPF FRQ - Cutoff frequency: TROUGH (off) / 30 / 40 / 50 / 60 / 70 / 80 / 90 /
100 / 120 / 150 / 180 / 220 / 250 Hz.
R-HPF SLOPE - Slope: 6 / 12 / 18 / 24 dB per octave.
R-HPF GAIN - volume level, from -8 dB to 0 dB.
Subwoofer LPF - setting the LPF and subwoofer phase.
SW LPF FRQ - Cutoff frequency: TROUGH (off) / 30 / 40 / 50 / 60 / 70 / 80 / 90 /
100 / 120 / 150 / 180 / 220 / 250 / 300 / 400 / 500 / 600 / 700 / 800 Hz.
SW LPF PHASE - electrical phase changeover: 0 ° / 180 °
SW LPF GAIN - volume level, from -8 dB to 0 dB.
SW LPF SLOPE - Slope: 6 / 12 / 18 / 24 dB per octave.
2-WAY (Standard)
