6
1- Make sure that the installation is protected against possible freezing.
2- Do not intervene in the waste water system.
3- However, if muddy water (clay etc.) comes out of the pipe, close the
water inlet valve of the system.
4- If you wish to use a water supply system other than the local water
supply system, it must be subjected to a drinking water analysis by the
responsible institutions.
5- If the water used is not tap water, make sure that the water is properly
disinfected.
The
ters are considered accessories and are not covered by the warranty.
Clean water
Waste water
Fig. 4: Installation of the reverse osmosis system
WARNING!
Tap water
1- Cebilon reverse osmosis system
2- Water inlet valve
3- Water inlet
4- Waste water outlet
5- Clean water outlet
6- Waste water clamp
7- Tap
7
6
2
1
5
4
3
3
