7
Close the water inlet valve.
After the remaining water in the tubes has been drained at the appropriate
points, connect the 3-way adapter to the water inlet. Make sure that there
are no leaks.
First, install the 1/4 " ball valve on the adapter by wrapping it with Teon
tape in a position that allows easy opening and closing of the ball valve
(Fig. 5 a).
Then, connect the water supply hose to the ball valve (Fig. 5 b).
Make sure that the ball valve is closed (Fig. 5 c).
Open the water inlet valv
e and check the installation for possible leaks
(Fig. 5 d).
Place the system in a suitable place under the sink in an upright position.
Fig. 5: Water connection ttings
WATER CONNECTION
