Aura FIREBALL-6.8 - Input and Output

AUDIO
RMS Power:
25W * 8CH @4Ω，50W * 8CH @2Ω
Frequency Response:
20Hz~20kHz
DSP Processor:
Cirrus Logic
Signal Converter A/D :
Cirrus Logic
Signal Converter D/A:
Cirrus Logic
Bluetooth :
Built in Bluetooth 5.1
INPUT AND OUTPUT
High level speaker input:
6CH
Low level AUX input:
2CH
High level speaker output:
8CH
Low Level RCA Output
8CH
DSP RCA output:
8CH (RMS 2V)
High input impedance:
13 Ω
Low input sensitivity:
0.5-2.5V
High input sensitivity:
4-10V
Optical Input: Yes
Sampling Rate: 24Bit/192KHz ADC/DAC
EQ/Delay: 31Band EQ/15ms
Filtering Crossing Point: 20-20KHz
GENERAL REQUIREMENTS – PC Software
PC connections:
USB 2.0
Software/PC requirements:
Microsoft Window (32/64bit):
(XP, Vista, Windows 7, Windows 8, Windows 10)
Operate temperature range:
-30~70℃
Size:
195(L)x131(W)x46.5(H)mm
Weight (Kgs)
1.3 Kgs
