Specifications
Frequency Response
z 3Hz - 300KHz, +/- 3dB
z 20Hz - 20KHz, +/- 0.1dB
THD+N
<0.002%, 20Hz-20KHz at rated output
Dynamic Range
>130dB, 20Hz-20KHz, A-weighted
Crosstalk
<-80dB at 1KHz
Output Power
STD Mode BAL Mode
32ohm
4500mW 1200mW
120ohm
1200mW 4500mW
300ohm
500mW 2000mW
600ohm
250mW 1000mW
Input Port
z RCA: Sensitivity: 2Vrms; Maximum: 6Vrms
z XLR: Sensitivity: 2Vrms; Maximum: 6Vrms
Output Port
z 6,35mm Stereo Headphone Jack (STD only)
z 4PIN XLR Headphone Jack (AKG K1000 wiring)
z RCA analog out (STD only)
z XLR analog out (PIN2:HOT)
Power Dissipation
50 Watts at max.
Dimension
11''W x 9''D x 2.6''H (33cm x 23cm x 6.5cm)
Weight
12 lbs (5.5kg)
All specifications are subject to change without notice.
