9
double caution NOT to short any pin of any analog output to ground.
NEVER SHORT ANY OUTPUTS OF VEGA TO GROUND!
FAILED TO DO THAT WILL DAMANGE THE UNIT
PERMANENTLY AND WILL AVOID ANY WARRANTY!
AES/EBU and S/PDIF Digital Inputs
The AES/EBU balanced digital input and three sets of S/PDIF coaxial inputs are de-
signed with individual input buffer circuit. The balanced and coaxial digital input
channels are transformer coupled to eliminate the EMI. The maximum sampling rate
supported by these ports is 24 Bit / 192 KHz.
USB 2.0 High Speed Input
The USB 2.0 Input uses asynchronous transmission mode and is buffered by
AURALiC's ActiveUSB technology to future reduce jitter effects. The USB input sup-
ports PCM signals up to 32 Bit / 384KHz as well as DSD streams at 2.8224 MHz and
5.6448 MHz through DoP V1.1 protocol. The specific driver is required for proper
functioning under Windows PC system, please refer to ‘USB Driver Installation’ on
page 13.
Power Cord Socket
We suggest you using a standalone power supply for VEGA to isolate it from other
digital source components using switching power supply for best sound quality. The
power consumption of VEGA is less than 20W, so a heavy gauge power cord is not
recommended as the weight of the power cord connector may damage the power
cord socket on the back of the unit. Please double check the AC mains voltage on the
back of the unit before connecting to the power.
