Description of the AURATON RT receiver
Legend - description of LED signalling
The AURATON RT receiver works with the wireless AURATON R25 RT controller. The
received is installed near the heang or air condioning device and may work with the
load of 16A/10A.
mounng hole
detachable 230V power
supply connecon
terminals
detachable control
connecon terminals
mounng hole
power buon
power supply
diode
buon for unpairing devices
diode indicang that
the actuator device has
been switched on
diode indicang that
the actuator device has
been switched o
buon for pairing
devices with the
RT receiver
The LED light’s green – the output device is o
(the contacts COM and NC are closed).
The LED light’s red – the output device is on
(the contacts COM and NO are closed).
The LED ashes green – the RT receiver awaits the device to be paired
(chapter: “Pairing the AURATON R25 RT wireless regulator and the RT
receiver”).
The LED ashes red – the RT receiver awaits the device to be
deregistered (chapter: “Deregistering the regulator from the RT
receiver”).
Green power supply diode – the RT receiver is switched on.
The LED ashes alternang red and green:
ALARM - the RT receiver has lost connecon with one of the paired
devices (chapter “Special situaons”).
RESET - receiver deregisters all previously paired devices
(chapter “Deregistering all devices paired with the RT receiver”).
