ONT-2-E4xxxi Multi-service Residential Gateway Series Hardware Installation Guide
16 UNRELEASED DRAFT TM 87-10879 Rev. A
LED
Color
Status
Description
LAN1, LAN2,
LAN3, LAN4
(Data Link/Activity)
Dark Off
No link has been established at the LAN interface, or
the interface is administratively disabled by the service
provider.
Green-Solid On LAN port is up.
Green-Blinking Blinks
Data is being transmitted or is received.
VoIP
(all models except
ONT-2-E4000i)
Dark Off
The ONT has failed to register with the Call Agent (SIP
server), or
Voice services have not been provisioned.
Green-Blinking Blinks To be determined.
Green-Solid On To be determined.
Voice Diagnostics:
 Phone1
 Phone2
(all models except
ONT-2-E4000i)
Dark Off
There is no phone is connected to the indicated line, or
The phone port is disabled, or
The phone port is enabled, but the attached phone is
on-hook.
Green-solid On To be determined.
WiFi (Wireless)
(ONT-2-E4020iWn
ONT-2-E4021iWn)
Green-Solid On A wireless connection is established via the web GUI.
Green-Blinking Blinks Data is being transmitted or is received.
WPS
Dark Off WiFi Protected Setup (WPS) – status to be determined.
USB
Dark Off Reserved for future use.
RF
(for RF-capable
models:
ONT-2-E4021i,
ONT-2-E4021iWn)
Dark Off RF video is disabled.
Green-solid On RF video is enabled with 1550 nm RF output.
3.5 Rear Panel and Interface Description
Ports on the ONT-2-E4xxxi Multi-service Residential Gateway Series are located on the rear panel. See
Figure 2 for a picture of the ports on an ONT-2-E4020iWn.
