Austroflamm Mo Duo - Clou Duo

29 english
10.2. Clou Duo
Nominal thermal output (NWL)
7 kW
Partial-load thermal output
2,3 kW
Space heating capacity
98 – 190 m³
Efficiency
89 %
CO content at NWL
<250 mg/Nm³
Flue gas temperature at NWL
188 °C
Flue gas temperature at TL (partial load)
90 °C
Flue gas mass flow rate at NWL
4,8 g/s
Flue gas mass flow rate at TL (partial load)
2,7 g/s
Minimum delivery pressure
12 Pa
Capacity of Pellet container
ca. 22 kg / 34 l
Min./max pellet consumption
0,6 – 1,64 kg/h
Min./max autonomy
ca. 13 – 36 h
Air connector Ø
125 mm
Flue connector Ø
130 mm
Electr. power input at switch-on
325 W
Electrical power input in operation
15 W
Voltage/current frequency
230 V / 50 Hz
Dimensions
H x W x D
1013 x 810 x 410 mm
Weight
212 kg
Minimum distance
at the sides
200 mm
at the rear
100 mm
at the front
800 mm
Temperature limits
0 – 40 °C
Relative humidity
Non-condensing
Flue outlet
Suppy air
Air distribution module
