7-19
CONNECTION OF SERVICES
External Temp
265ºC
Battery Current
5.4 Amps
Waste Water
0% Full
Water level in the waste water tank
(2 measurement levels).
If the water pump power switch is
turned ON and the waste water level
rises to 100% a warning beep will be
heard and the LCD display will flash.
To cancel the warning, press the
(
) button. The warning will not be
repeated unless the water pump
power switch is turned off and on
again. This is to ensure the warning
does not become a nuisance.
Display
Description
Options / Notes
0% < 1/2 Full
50% > = 1/2 Full (optional level
that is not normally fitted by
most manufacturers)
100% = Full
External temperature (in degrees
centigrade) as measured by the
external temperature probe
(Only available in H specification
systems - see start of section 4.2)
Current (in Amps) being drawn from
or charged into the selected battery.
If a solar panel is fitted this display
will include the current being
provided by the solar panel.
(Only available in H specification
systems - see start of section 4.2)
Negative figure (-) = current being
drawn from the selected battery.
Positive figure (+) = current being
used to charge the selected
battery
