33
Select Rope per turn.
Enter the measurement in mm or metric inches (depending
on the units selected). See the table above for metric
inch calculations.
Save and return to Rode Set up.
Exit to Windlass Set up.
Press to exit to the Set Up menu and press again to return to
the start up screen.
3.8.6 TO ENTER THE ROPE PER TURN
Step 3 Using the mark on the chainwheel as
a guide, pull the rope out by hand
until the chainwheel has completed
10 turns.
Step 4 Measure the length of rope pulled,
divide it by 10.
Step 5 Enter this measurement (See below)
.
Setting:
Chainwheel Mark
Chain Mark
Deck Mark
Distance to Measure
3.9 DRUM WINCH SET UP
Access via the Windlass Set Up Menu. 3 settings are required:
Total Rode Length.
Inside Diameter.
Outside Diameter with rode retrieved.
Turn the AA710 remote console off.
Hold together to access the Set up menu.
Scroll to Windlass.
Select Windlass.
3.9.1 TO ACCESS THE WINDLASS SET UP
3.9.2 SET TOTAL RODE LENGTH
Add total length of chain plus total length of rope
Defaut = 60m or 196ft. Minimum setting = 10m (33ft).
Scroll to Total rode length.
Select Total rode length.
Increase or decrease the value in meters or feet.
Save and return to Windlass Set up.
Setting:
3.9.3 SET RODE
Scroll to Rode.
Select Rode.
Select Drum winch.
Setting:
To Next Page
