Accessories table
Spare screws（M5x16mm）x1 Spare screws（M8×20mm）×1
Spare screws（M8×30mm）×1 Screw for the recliner adjuster（M5x16mm）x2
3 4
5
5
wrench×2
01 02
03 04
05 06
Insert the chair wheel into the base
Unscrew the backrest screw and place the backrest
as shown
Fix the backrest with backrest screws
（Note: The four backrest screws are aligned with the holes in sequence and
then tightened）
Buckle up the cover of the recliner adjuster as shown in
the figure and fix it with the recliner adjuster screw
Screw holes for backrest
Screw holes for backrest
（Fix the bottom buckle first）
Place the chair as shown and unscrew the Tilt mechanism
screws and armrest screws
（Note: Pay attention to the length of the Tilt mechanism screws and armrest screws）
Insert the Cylinder into the base
（Note: The initial shortest state just after getting the Cylinder）
Screw hole of cover of the
recliner adjuster
To Next Page
