AUTOHELM NMEA BRIDGE - Page 10

NMEA Bridge Operation and Installation Handbook
10
Cabling
The NMEA Bridge should be connected to SeaTalk and the
other manufacturer's equipment as follows:
D1771-1
NMEA
SEATALK
ALARM
OUT
+ –
Screen (0v)
Yellow (Data)
Red (v+)
Red
(v+)
Screen
(0v)
+
-
Power
5A
IN
+ –
OUT
+ –
RS232
SEATALK
NMEA
+ –
