NMEA Bridge Operation and Installation Handbook
18
PC Serial Port Connections to NMEA
The following diagram shows the pin connections for 25 and 9
pin PC serial ports to NMEA.
2
Ground
Receive
Transmit
3
7
2
Ground
Receive
Transmit
3
5
DB25 25 PIN
SERIAL CONNECTOR
DB9 9 PIN
SERIAL CONNECTOR
D1773a-1
