-2-
Description & Operation
Filter Assembly General Description (Figure 1)
The CSB electric self-cleaning brush filter enables high quality filtration at filtering
degrees of 200-4000 micron from different types of fluid sources such as sewage,
reservoirs, rivers, lakes, and wells.
The CSB filter contains the following parts:
1. Inlet 4. Flushing Valve (HYD or Electric)
2. Screen 5. Electric Motor
3. Brush 6. Outlet
Figure 1: Filter Assembly
