-4-
Technical Data
Standard Features
• Minimum operating pressure: 3 bar (45 psi)
• Maximum operating pressure: 10 bar (150 psi)
• Clean filter pressure loss: 0.1 bar (2 psi)
• Maximum water temperature: 90°C (200°F)
• Filtration range: 200 - 4000 micron
• Electric motor: 3-phase 0.5 Hp
• Flush water consumption (at minimum working pressure): 70 liters (18.5 gallons)
• Filter housing materials: carbon steel coated with baked on epoxy, or
stainless steel
General Technical Data
Filter Model M3/h GPM Screen Area Sq/ft
CSB 4 100 400 5
CSB 6 200 800 5
CSB 8 300 1,200 5
CSB 10 450 1,800 7
CSB 12 650 2,600 11
CSB 14 1,000 4,000 12.5
CSB 16 1,500 6,000 16
L = 90
O
Connections IL = Inline connections
* Flow rate data are for high quality water at filtration grade of 200 micron.
** Flushing flow rate data are for minimum operational pressure (1 bar / 15 psi).
Filtration Grade Conversion Table
Micron
200 400 800 1500 3000
Mesh
80 40 20 10 5
