Automatic Systems TR491-TR6-GB-a YD-JMW 20/01/00 Installation TR491 2-1106GB Rev.: C p. 12/12
3.6. Temporary dismantling
• If the equipment has to be temporarily dismantled, e.g. if you need to change its location, follow
the procedure below.
3.6.1. Disconnecting the equipment
-- Unlock and open the front doors (4:1) and (4:2).
-- Unlock and remove the hood (4:3).
-- Make sure that the power supply cables are not live.
-- Put off the main switch (2:1) near the electrical control logic.
-- Disconnect the power supply wires (2:4) from the main switch (2:1) as well as the earth
cable (2:5).
-- Disconnect any other cabling (control wires, etc.).
3.6.2. Removing the unit
-- Loosen the four expansion bolts inside the front and rear end sections, at the bottom of the
housing.
-- Remove the two fixing brackets from the turnstile.
Note: Either remove, or cut off floor fixing expansion bolts and make good the floor
surface, protruding fixings are a dangerous risk to the health and safety of persons
using the area.
-- Using manual handling or fork-lift truck remove the tripod turnstile to safe or its new location
for installation.
3.7. Scrapping the equipment
• When the equipment is withdrawn from use, proceed with the dismantling procedure as
described in paragraph [3.6. Temporary dismantling]. Ensure that the various components of the
equipment (metals, electrical components, plastics, etc.) are handled, recycled, or disposed of in
the appropriate method, to comply with regulations and codes of practice in the country where the
unit is to be scrapped.
