AutomationDirect DL205 Instruction

Wiring Diagram power supply and cable
ZL-CM08L120
Cable ZL-2CBL1
ZL-CM08L120
110Vac
I/O Module Input Octal Address 0 corresponds to LED 0
A1 A1 A1 A1 A1 A1 A1 A1
A2 A2 A2 A2 A2 A2 A2 A2
I/O Module Input Octal Address 1 corresponds to LED 1
I/O Module Input Octal Address 2 corresponds to LED 2
I/O Module Input Octal Address 3 corresponds to LED 3
I/O Module Input Octal Address 4 corresponds to LED 4
I/O Module Input Octal Address 5 corresponds to LED 5
I/O Module Input Octal Address 6 corresponds to LED 6
I/O Module Input Octal Address 7 corresponds to LED 7
A1 A2
C0 1 2 345 6 7
Warning :
It is recommended to install
a 2 Amp fast blow fuse in series with
the power supply as an extra safety
measure.
Use a fuse terminal block such
as a DINnector DN-F10 or DN-F10L
COMPATIBLE WITH CONNECTION:
TYPE: TYPE:TYPE: TYPE:
EF GH
PLC DL 205 Type D2-08NA-1
AC Input I/O Module
REV 1.1PAG. 3
