Page #49 background imageLoading...
Page #49 background image
Dose Rate Meter 6150...
AD1
AD3
AD5
AD1/H, AD1/E
AD3/H, AD3/E
AD5/H, AD5/E
AD2
AD4
AD6
AD2/H, AD2/E
AD4/H, AD4/E
AD6/H, AD6/E
Battery life (with 6LR61):
without illumination
with illumination
approx. 1000 hours (3000 hours with hardware release 3)
approx. 60 hours
Battery check
voltage is indicated digitally after switching on,
or later if requested with the function key
Supply voltage
nominal range 5.5 to 10 Volt
Battery monitoring
automatic visual and audible warning
if battery voltage drops below 5.5 Volt
Housing
aluminium die-cast, waterproof,
protection class IP 67 according to DIN 40050
Buzzer
piezo buzzer inside the housing
Dimensions
130 x 80 x 29 mm³
Weight
approx. 400 g
Carrying strap
plastic, easy to decontaminate, length 1 m
14
.
2
Source Holder 761.1
Application
holder to mount check source 6706 onto the 6150AD
Dimensions
150 x 90 x 38 mm³
Weight
approx. 260 g
Material
grey plastic
14
.
3
Wall Holder 761.8
Application
wall holder to store the 6150AD
Dimensions
165 x 90 x 45 mm³ including holding screw
Weight
approx. 330 g including holding screw
Material
grey plastic
Mounting
requires two countersunk screws (not included)
03/2004
Operating Manual 6150AD
Page
45
Daimlerstrasse 27
Telefon
+49(0)6203-9503-00
http://www.automess.de
USt.-ID-Nr. / VAT ID No.
D-68526 Ladenburg
Telefax
+49(0)6203-9503-29
eMail: info@automess.de
DE 144 458 420
