Output mode selection
Memory protection(ON/OFF)
Max. counting speed
Counter/Timer
Up/Down mode selection
Count input mode(Counter)
Time setting mode(Timer)
Description of inner DIP switches
● Up/Down mode
● Counter/Timer selection
● Memory protection
※
Inner selection switch is changed from 10pin
to 11pin with upgrade of counting speed.
※
There is no output operation mode in
indication type(FX5S-I) and SW2 selection
switch.
SW1 CP1, CP2
1cps
30cps
2kcps
5kcps
SW1 Function
4
Down mode
Up mode
SW1 Function
5
Counter
Timer
SW1 Function
8
Disable the memory protection
Enable the memory protection
ON
OFF
ON
OFF
ON
OFF
ON
OFF
67
ON
OFF
67
ON
OFF
67
ON
OFF
67
ON
OFF
ON
OFF
ON
OFF
● Max. counting speed
ON
ON
OFF
※
321 87654321
SW2
SW1
Setting function of Decimal point
Dispaly the decimal point.
※
It returns to RUN mode if no RESET button or digital switch is applied for 60sec. in decimal point setting status.
※
The decimal point setting is not existed in indication type.
(Factory default)
※
If press RESET button for
over 3sec. it advanced to
decimal point setting
mode.
※
It returns to RUN mode
by press RESET button
over 3sec.
※
When "
" fl ashes,
touch RESET button
once.
※
Set the position of decimal
point using , buttons
of digital switch.
RUN mode Return to RUN mode
● Changing the decimal point
Up/Down Counter/Timer
