Pour the TWC detergent into the bottle. Open the Ball Valve
and Air Pressure Regulating Valve to keep the air pressure as
zero.
Connect the TWC Flushing Kit to the output pipe of the C80.
Disconnect the Intake Vacuum Pipe which near the throttle
and insert the TWC Flushing Nozzle into Intake Vacuum Pipe
as shown.
The operating procedure of TWC and intake manifold flushing:
Intake Vacuum Pipe
Start the engine, and open the Ball Valve slowly which be sure
to make the detergent into engine vacuum pipe very slowly.
The flushing process needs about 30 or 40 minutes.
Keep the engine speed up to 1000 rpm and press the
accelerator every 3~5 minutes to make the engine speed up to
2000 ~ 3000 rpm and keep this state for 30 seconds. Then
keep idle speed.
Do the flushing procedures as above until to exhaust the
detergent. Then stop engine and reconnect the vacuum pipe.
Start engine as idle speed for about 5 to 10 minutes to exhaust
the detergent in the pipe.
Pour the Throttle Body detergent into the bottle, and close the
Ball Valve of the fuel outlet pipe. Open the ball valve of the air
inlet port and connect to the compressed air. Adjust the air
pressure to about 0.5MPa（ 5kgf/cm2） and then close the
Ball Valve of air inlet port.
Connect the spray nozzle kit to the fuel outlet port of the C80.
The operating procedure of Throttle body and exhaust pipe
flushing:
Remove the pipe ahead of throttle before flushing as shown.
Put the spray nozzle kit in the throttle body as shown and start
the engine. And then open the Ball Valve of fuel outlet port .
5
6
