AUTOPMALL MV720 - 1. Main Features; GPS, GLONONASS, LBS Positioning; Remote Fuel Control and Resume; Route Playback and Real-time Tracking

1. Main Features
GPS+
Remotely Cut Off Historical Route
Realtime 9-90V Wide
GLONASS+LBS
Vibration
Alarm
/Resume Fuel
Power
Disconnect Alarm
Playback
Geo-fence
Tracking
Overspeed
Alarm
Working Voltage
Lifetime Free
Tracking Platform
2.Specifications
Device Information
Model
MV720
Weight
53g
Dimensions
31mm(L) * 31mm(W) * 57mm(H)
Working Parameters
Working Voltage
DC 9-90V
Working Current
<30 mA
Sleep Current
<15 uA
Battery Capacity
3.7V 80mAh Lion Polymer battery
Working Temperature
-20℃ - 75℃
Working Humidity
10%-85%RH non-condensing
Cellular Specifications
Working Frequency
2G GSM/GPRS: 850/900/1800/1900MHz
SIM Card
Nano SIM Card
Cellular Antenna
Built-in
GNSS Specifications
Positioning Type
GPS+GLONASS+LBS
GPS Antenna
Built-in
Cold Start
≤32 Seconds
Hot Start
≤1 Second
Tracking sensitivity
-162 dBm
GPS Channels
64
Position Accuracy
5-10m
