appEnDix c
ADDITIONAL APPROVALS
The following items, functions, and options describe various other approvals applicable to the AutroPath HC800.
SIL APPROVAL
IEC 61508: 2010 Parts 1-7
Certified SIL 2 Capable.
Refer to the Safety Reference Manual for details.
DNV GL
Type Approval Certificate No. TAA000002M.
Subject Matter of the Approval
AutroPath HC800 Infrared Gas Detector is found to comply with Det Norske Veritas’ Rules for Classification of
Ships and Det Norske Veritas’ Offshore Standards.
Application
Location Classes
MODEL TEMPERATURE HUMIDITY VIBRATION EMC ENCLOSURE
LS2000 D B A/B B C/IP66/IP67
Relevant tests according to “Standard for Certification No. 2.4.”
Location classes for HC800 (Shaded areas show Autronica approved location classes)
COLUMN 1 COLUMN 2
TYPE LOCATION WITHIN MAIN AREA
MAIN AREAS ON BOARD
Machinery
spaces
Control room,
Accommodation
Bridge
Pump room, Holds,
Rooms with no heating
Open
Deck
Temperature
Inside cubicles, desks, etc. with temperature
rise of 5°C or more
B B B D D
All other locations A A A C D
Humidity
Locations where special precautions are
taken to avoid condensation
A A A A A
All other locations B B B B B
Vibration
On machinery such as internal combustion
engines, compressors, pumps, including
piping on such machinery
B — — B B
Masts — — — — —
All other locations A A A A A
EMC (Electro-
magnetic
compatibility
All locations within specified main areas A A B A B
Enclosure
Submerged application D — — D D
Below floor plates in engine room C — — — —
All other locations B A A B C
