AUX ASW-09A4/H User Manual

Indoor Unit
Operating step Photo
1. To remove the panel and connecting wire
cover.
· Take off the screws of the connecting wire
cover and remove the cover.
· Then remove the panel.
2. To remove the air filter.
3. To remove the inter frame assembly
 Take off three screws of inter frame
assembly
 Then take off the inter frame assembly
4. To remove the electric control box
 Take off one screw
 Loose one obverse clip
 Remove the electric control box

AUX ASW-09A4/H Specifications

General

Brand	AUX
Model	ASW-09A4/H
Category	Air Conditioner
Language	English
