Specification
Specification
Technical
I/O Connections
3 x HDMI In
1 x HDMI Out
I/O Resolution
Support
480p@60Hz, 576p@50Hz,
720p@25/30/50/60Hz, 1080i@50/60Hz,
1080p@24/25/30/50/60Hz,
4096x2160@24/25/30/50/60Hz,
3840x2160p@24/25/30/50/60Hz,
NOTE: 4096x2160/3840x2160@50Hz/60Hz is
based on chroma sub-sampling 4:2:0 8-bit
only
TMDS Impedance 100Ω
Input Video Signal 0.5~1.2 Vp-p
Input DDC Signal 5 volts p-p (TTL)
Control Method IR Control, Front Panel Control
General
Power Consumption 0.15W
Operating
Temperature
32°F to 113°F (0°C to 45°C)
10% to 90%, non-condensing
Storage Temperature
-4°F to 158°F (-20°C to 70°C)
10% to 90%, non-condensing
ESD Protection
Human Body Model:
±8kV (air-gap discharge)/
±4kV (contact discharge)
Surge Protection
Voltage: ±1k V
