FIREPLACE INSERT - SPECIFICATIONS
LOCATION OF FLUE COLLAR DIMENSIONS REQUIRED FOR INSTALLATION INTO FIREPLACE AND
PANEL SIZING. WHEN INSTALLING THE 996 EXTENDED 45
o
FLUE, MAKE ALLOWANCE FOR THE
DISTANCE THAT THE 45
o
ELBOW WILL EXTEND PAST THE BACK OF THE INSERT.
TOP VIEW
996 Flush Top Flue 996 Extended 45
o
Flue
24
1/8"
4"
25 5/8"
19
3/8"
12 13/16"
15"
Firebox Front
24
1/8"
25 5/8"
19
3/8"
12 13/16"
3 5/8"
Firebox Front
10
3/8"
FIREPLACE SIZING
Measure and center the appliance into the fireplace based on the provided measurements.
A. Minimum Height
(Front)
B. Minimum Height
(Back)
C. Minimum Width (Front)
D. Minimum Width (Back)
E. Depth into Fireplace
F. Extension onto Hearth
996
Flush
Top Flue
21 3/4"
21 3/4"
25 5/8"
25 5/8"
14"
5 3/8"
996
Extended
45
o
Flue
21"
21"
25 5/8"
25 5/8"
9 3/8"
10"
A
D
C
B
E
F
