Parts Iden fi ca on
Control Panel
Handle
Horizontal Louver Control
Lever (adjust manually)
Front Panel
Air Outlet
Castors (4)
Con nuous
Drain Outlet
Upper Air Intake
(Evaporator)
Upper Air Filter
(behind grill)
Remote Sensor
Lower Air Intake
(Evaporator)
Lower Air Filter
(behind grill)
Bo om Drain
Outlet
