Avalon Olympic 1190 - Fireplace Requirements

Fireplace Insert Installation (for qualified installers only) 19
© Travis Industries 93508061 4050526
Fireplace Requirements
Figure 16 shows the minimum size requirements.
a
c
e
f
22-1/4"
22-1/4"
29-3/8"
29-3/8"
11-5/8"
24-7/8"
45-3/8"
56-3/8"
52-1/4"
39-1/4"
54-1/4"
41-1/4"
Standard
Model
Cook-Top
Model
Minimum
Fireplace Size
a
b
c
d
e
f
g
h
i
j
Height (front)
Height (rear)
Width (front)
Width (rear)
Depth
Hearth Depth*
Hearth Width
Facing Width
Facing Height
with Mantel Shield
Mantel Height
with Mantel Shield
22-1/4"
22-1/4"
29-3/8"
29-3/8"
14-1/8"
22-3/8"
45-3/8"
56-3/8"
51-1/4"
38-1/4"
53-1/4"
40-1/4"
* This is the distance the insert protrudes from
the fireplace opening plus the required 16" of
hearth extension.
b
d
h
i
j
g
Non-Combustible Hearth
Combustible Mantel
Non-Combustible Facing
Figure 16
