AVALON V5 REAR PANEL CONNECTIONS
AC
input
EARTH
lift
LINE
out
THRU
out
ISO
out
LINE
input
PHONES
out
MIC
input
AC
inp
1
LIN
out
3
THR
out
THR
4
EA
lift
EA
LIN
2
AC VOLTAGE SELECTOR. Select for either 115v or 230v.
FUSE 5mm slow blow type : 115v = 0.2A, 230v=0.1A.
Switch isolates chassis ground from audio signal gound,
UP position is LIFTED.
Dual TRS Jack and XLR BALANCED outputs, DC coupled,
high-current, 600 ohm, +30dB maximum.
THRU output is BUFFERED from Instrument DI input
located on front panel. Ideal for amplifier inputs or tuners.
The ISOLATED (RE-AMP) output is transformer isolated
via the TRS jack. Signal is UNBALANCED +12dB maximum.
XLR BALANCED and TRS (balanced) jack line input,
transformer isolated, +45dB maximum input, pin 2=hot.
Headphone TRS jack 0.5W maximum 600 ohms.
XLR BALANCED microphone input, transformer isolated,
+23dB maximum input, pin 2=hot.
1
43
PANEL C
5 8
6 7
2
AVALON
D E S I G N
AVA L ON
D E S I G N
LIFT
115v
FUSE
EARTH
- 18dB to AMP
OUT
LINE OUT THRU PHONES
PUS HPUS H
SERIAL NO.
50/60Hz AC 35W MAX.
MIC INPUT
L
INE IN
LINE INPUT+30dB MAX
BALANCEDBA L A N CEDBA L A N CED
OUT
V 5
5
MADE IN CALIFORNIA, U.S.A.
Rack Mount Kit RM-2 showing BLACK option U5 and V5.
