Avalon A-Series Disassemble Guide QS-AMS-OS-001（A/0）
8 / 10
Step 10:
Additional Information:
⚫ Take out the fixed screws (18 in
totals) and remove the heat
sinks of the hash boards on both
sides.
(A hash board comprises three
heat sinks in the rear and one
heat sink in the front.)
- The top view of a front heat
sink.
- Be aware that holes are
unequally distributed in
vertical direction.
Note: be sure to align the hash board with heat sinks before fastening.
- A hash board is perfectly in
alignment with heat sinks.
