Avantco MX40 - Three Phase Motor Diagram

User Manual
14 www.AvantcoEquipment.com
THREE PHASE MOTOR DIAGRAM
Figure 9
FIGURE 9 STANDARD ACCESSORIES
AND ELECTRIC DIAGRAM
2
1
3
4
Mixing device I
Bowl
1
1
1
1
1
2
3
4
12
Mixing device II
Mixing device III
Descviption
Qty
1
TheB40foodmixeristhenewproductofBseriesofUniversal
foodmixer.Itcanmix,grindtheflourandliquidfood. Thedesign
iswithbeltandgeartransmission. Themixermakesgooduseof
planetprinciple,sotheagitatorrunsinthematerialbarreljustlike
theplanetanditcanmixfoodsmoothlyandfully. Themachineruns
withseveralspeedsandmanytypesofagitatorssteadilyandfirmly,
thecustomerscansatisfywithitaccordingtodifferentrequirements.
Allsparepartsoftouchingfoodarestainlesssteelordealtwithspec-
ialoperation,andtheycanmeasureupthenationalhealthful standard.
Thismachinehasgoodshape,andisoperatedsimply.Safety,heal-
thfulandhighefficiency,itissuitableforhotels,restaurants,foodpr-
ocessingfactoriesandfoodcanteens.Italsocanbeusedforthemedi-
calandchemicalrawmaterialfactories.
Youuseandmaintainthemixercorrectly,itcangiveyouthesatisf-
iedeffectforalongtime.
Introduction
B40F/B40FA MIXER USER MANUAL B40F/B40FA MIXER USER MANUAL
1C
NL
PE2
K4
1C AC contact device
K2 bowl lift switch
K3 safety protect switch
K4 urgency stop switch
K5 start switch
K0 point-move switch
CA CB capacitor
M motor
¡¢
M
K5
CA
K2 K3
K0
C
CB
1. 1 Phase Motor diagram:
2. 3 Phase Motor diagram:
M
1C
FR
L2 L3L1
PE
FR3
K1
FR relay
1C AC contact device
K2 bowl lift switch
K3 safety protect switch
K5 start switch
M motor
K1 urgency stop switch
K2 K3
K5
C
K5
177MX40
SPECIFICATIONS
Type MX40
Capacity 40 QT.
Power Supply 240V
Phase 1
Input Power 1300W
Hertz 60 Hz
Horsepower 2 HP
Max. Flour Capacity 25 LB.
