Avanti CTW84X0W-IS User Manual

17
OPERATING INSTRUCTIONS
PRESS THE POWER BUTTON.
PRESS THE PROGRAM SELECTION BUTTON.
Choose the desired function and then the corresponding indicator blink.
1
NORMAL
5
SPIN ONLY
2
COTTON
6
WHITES
3
GENTLE WASH
7
HEAVY SOILED
4
SPEED WASH
8
TUB CLEAN
PRESS THE LOAD SIZE BUTTON.
Choose appropriate water level according to wash load quantity.
(In SPEED WASH program, the water level cannot be selected)
NOTE: The washer will provide a cold rinse in all settings.
IMPORTANT: A single cold hose system does not allow the washing machine to automatically
(select) regulate incoming water temperatures.
PRESS DOWN START/PAUSE BUTTON ONCE AND THE MACHINE WILL BEGIN OPERATION.
Please press this button to stop the normal operation, if it continues to work, press it again.
Water level can be reset during the normal operation. If the higher water level is selected, the machine
will operate after refilling the water level selected.
FULLY AUTOMATIC – FUZZY LOGIC PROGRAM.
Your machine incorporates the fuzzy logic program, which will automatically select the load size and
select the cotton wash program.
Press the Power button.
Press the Start / Pause button, the tub will start to spin back and forth the weigh the clothes in the tub
and then will be operation.
The machine will work in the Cotton wash program as a default.
AUTOMATIC WASH PROGRAMS
NOTE: All automatic wash programs include soak time.
1
SMALL
2
MEDIUM
3
LARGE

Avanti CTW84X0W-IS Specifications

General

Door hinge	Up
Display type	LED
Loading type	Top-load
Tub material	Stainless steel
Product color	White
Built-in display	Yes
Custom panel-ready	-
Appliance placement	Freestanding
Drum capacity	- kg
Maximum spin speed	- RPM
Noise level (spin)	- dB
Number of washing programs	8
AC input voltage	120 V
AC input frequency	60 Hz
Energy consumption washing per cycle	- kWh
Package depth	508 mm
Package width	483 mm
Package height	851 mm
Package weight	21772 g

Weight and Dimensions

Depth	464 mm
Width	445 mm
Height	794 mm
Weight	19051 g
